Dapol OO 4S-006-051S BR 5819 ex-GWR 58xx Class 0-4-2T Black Early Emblem DCC Sound

Designed by C B Collett in the early 1930s for auto train services the 48xx class was based closely on the Armstrong 517 class 0-4-2Ts which had proved highly capable on these duties. The new engines were an updated design, incorporating all the updates done on the 517s and a more modern, higher pressure boiler. 75 engines were built equipped with auto gear for working with trailer cars, with an extra 20 non-auto engines of the 58xx class. Post-war the 48xx class engines were renumbered into the 14xx series.
This model replicates non-auto fitted 5800 class locomotive 5819 in 1950s condition finished in British Railways plain black livery with early lion over wheel emblem. Factory fitted DCC sound.

£250.00

MRP £250.00

Must be ordered - delivery as soon as possible.

(Product Ref 125801)

Cookies are disabled.
To place an order please call 01453 377030

Have a question about this product? Let us know

The 48XX and 58xx was designed to replace the earlier 19th century George Armstrong Wolverhampton 517 class. Charles Collett improved the design with new higher pressure boilers and an improved cab. A total of 75 14xx were built with auto gear for working with trailer cars and when introduced were numbered 48xx to 4874 with 20 non auto fitted 58xx class constructed for general purpose traffic. The first locomotives entered service in 1932, with most running into the 1960s. The 4800 with autocoach meant the locomotive could be controlled from there which negated the requirement to run the locomotive round at the end of the journey. This format was known as a push-pull train.
After the war experiments with oil firing of the 28xx class would be renumbered in the 48xx class, therefore the original 48xx class were renumbered 1400 to 1474. Four members of the class have been preserved 1420, 1442. 1450 and 1466.

General Specification

The locomotive will have all of the usual refinements that are expected to be found on all Dapol models including:

Diecast chassis, running plate, wheels (with metal tyres) boiler and fire box
Fully compensated chassis
Detailed cab interior
Bunker steps for the post 1936 examples
Removable cab roof (held in place with magnets)
Two footplate styles to represent the 48xx & 58xx, one or two footsteps on the front steps
Collett sprung straight shank buffers
High level of separately added details
Representation of internal motion
Topfeed where appropriate
Expertly applied liveries
Printed number plates with etched plates in the accessory pack

Technical Specification

A slide in PCB offers simple ‘tool-free’ installation of a NEXT-18 DCC decoder and a ’no-solder’ speaker connection. This board slides through the smoke box door and connects directly to the locomotive mother board.
Firebox glow (synchronised with sound - Factory fitted models only)
High quality coreless motor
Next-18 DCC Socket
DCC Ready, DCC fitted & DCC sound fitted options will be available.
Enhance your driving experience with our feature RealDrive (Factory fitted models only)
